LS-B5L 1 cavity semi automatic PET bottle blow molding machine for 100ML to 7L bottles

LS-B5L 1 cavity semi automatic PET bottle blow molding machine for 100ML to 7L bottles

LS-B5L-1 manual plastic bottle blower can produce different shapes from 100ML to 7L  mineral water bottles with handle , edible oil bottle with handle ,pesticide bottle, cosmetics bottles, and other plastic PET containers. High quality,low defect rate,easy operation.

Machine Parts

a.PLC controller and screen : Thinget(China)

b.Pneumatic parts:YongCheng (China)/Festo(Germany)

c.Valve parts: STNC (China)

d.Other parts are world-famous brands

Follow us on

Machine Features

  • A.Advanced PLC control system with convenient operation.
  • B.Precise infrared heating, the preform rotates by itself and on the orbit at the same time, with strong penetration and high heating efficiency.
  • C.Two ways of operate: automatic and manual.
  • D.Safety, high efficiency and energy saving.
  • E.Simple installation and operation.
  • F.Long time after sales service.

Product Detail

Model

LS-B5L-1

Theoretical output

400BPH

Heating capacity

8KW

Max bottle  volume

7L -1cavity

Blowing pressure

≦3.0MPA

Motion pressure

≦1.0MPA

Max diameter*height

Φ95*H320

Mould thickness

120-250MM

Weight

1000KGS

Main machine size

1800*620*1300MM

Heater size

1700*650*1450MM
